| Name | CPE206 | | Transmission distance | 2km | | Chip | AR9344 | | Flash | 8MByte | | Interface | 10/100Mbps LAN*2 | | Date Rate | 11a:54M,48M,36M,24M,18M,12M,9M,6Mbps;11n:7.2M,14.4M,21.7M,28.9M,43.3M,57.8M,65M,72.2M, 14.4M,
28.9M,43.3M,57.8M,86.7M,115.6M,130M,144.4Mbps | | Modulation Method | OFDM/BPSK/QPSK/CCK/DQPSK/DBPSK | | Frequency | 4900~6100MHz | | Power waste | ≤3W | | Power | DC12V POE 24V 1A | | Antenna | Frequency | 5180~5825MHz | | polarization | vertical (Horizontal 60°/vertical 30°) | | Gain | 12dBi | | Storage environment | Operating temperature | -30~60℃ | | Storage temperature | 0~40℃ | | Humidity | ≤95%(non-condensing) | | Size | 172*44.90 mm | | Packing size | 250*98*75mm | | Weight | 0.2kg | | Packing weight | 0.42kg |
|
